K1: Mode group, channel, program operation, reset response
9.5 Program test
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
501
Selection
This function is selected via the operator interface in the "Program control" menu.
The selection sets the following interface signal:
DB21, ... DBX24.6 (dry run feed rate selected)
This does not activate the function.
Activation
The function is activated via interface signal:
DB21, ... DBX0.6 (activate dry run feed)
Display
Active dry run feedrate mode is indicated by a reversal in the relevant field in the status line on the operator
interface.
9.5.4 Skip part-program blocks
Function
When testing or breaking in new programs, it is useful to be able to disable or skip certain part program blocks
during program execution. For this, the respective records must be marked with a slash.
Figure 9-1 Skipping part program blocks
%100
N120 M30
N80 ...
N30 ...
Main program/subroutine
N10 ...
N20 ...
/N40 ...
/N50 ...
N60 ...
N70 ...
N90 ...
N100 ...
N110 ...
Block being
processed
Skip blocks
N40 and N50 during
processing
