Page #145 background imageLoading...
Page #145 background image
A3: Axis Monitoring, Protection Zones
2.6 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
145
2.6.3.3 Signals to axis/spindle
Axis monitoring functions
Protection zones
None
Signal name SINUMERIK 840D sl SINUMERIK 828D
Follow-up mode DB31, ... .DBX1.4 DB380x.DBX1.4
Position measuring system 1 / 2 DB31, ... .DBX1.5/6 DB380x.DBX1.5/6
Controller enable DB31, ... .DBX2.1 DB380x.DBX2.1
Clamping in progress DB31, ... .DBX2.3 DB380x.DBX2.3
Velocity/spindle speed limitation DB31, ... .DBX3.6 DB380x.DBX3.6
Feed stop/spindle stop DB31, ... .DBX4.3 DB380x.DBX4.3
Hardware limit switch minus/Hardware limit switch plus DB31, ... .DBX12.0/1 DB380x.DBX1000.0/1
Software limit switch minus / 2nd software limit switch plus DB31, ... .DBX12.2/3 DB380x.DBX1000.2/3
Encoder limit frequency exceeded 1 / 2 DB31, ... .DBX60.2/3 DB390x.DBX0.2
Referenced/synchronized 1 / 2 DB31, ... .DBX60.4/5 DB390x.DBX0.4/5
Traverse command minus / plus DB31, ... .DBX64.6/7 DB390x.DBX4.6/7
