Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.1 Various interface signals and functions (A2)
Basic Functions
1620 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
19.1.5 Signals from operator control panel (DB19)
Signal state 0 or
edge change 1 → 0
Active file system
Application
example(s)
with HMI Advanced always 1
DB19
DBB17 PLC line offset in the user control file
Edge evaluation: No Signal(s) updated: Cyclic
Description This byte for controlling file transfer via the hard disk defines the line of the user control file in which
the control file to be transferred is located.
Application
example(s)
Valid for HMI Advanced, with reference to DB19 DBB13
Dependent on:
DB19 DBX14.7=0 → Akt. FS: PLC line offset in a standard control file
DB19 DBX14.7=1 → Pas. FS: PLC line offset in a user control file
DB19
DBX44.0 Mode change disable
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
Mode change disable active
Signal state 0 or
edge change 1 → 0
Mode change disable active
DB19
DBX45.0 FC9 Out: Active
Edge evaluation: No Signal(s) updated: Cyclic
DB19
DBX45.1 FC9 Out: Done
Edge evaluation: No Signal(s) updated: Cyclic
DB19
DBX45.2 FC9 Out: Error
Edge evaluation: No Signal(s) updated: Cyclic
DB19
DBX45.3 FC9 Out: StartError
Edge evaluation: no Signal(s) updated: Cyclic
DB19
DBX20.1 Screen dark
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change 0 → 1
The screen is darkened.
DB19
DBX16.7 Active or passive file system

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
