K1: Mode group, channel, program operation, reset response
9.17 Data lists
Basic Functions
678 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
9.17.3 Signals
9.17.3.1 Signals to NC
9.17.3.2 Signals to NC
9.17.3.3 Signals to NC
Signal name SINUMERIK 840D sl SINUMERIK 828D
Emergency stop DB10.DBX56.1 DB2600.DBX0.1
Signal name SINUMERIK 840D sl SINUMERIK 828D
AUTOMATIC mode DB11.DBX0.0 DB3000.DBX0.0
MDI mode DB11.DBX0.1 DB3000.DBX0.1
JOG mode DB11.DBX0.2 DB3000.DBX0.2
Mode change disable DB11.DBX0.4 DB3000.DBX0.4
Mode group stop DB11.DBX0.5 -
Mode group stop axes plus spindles DB11.DBX0.6 -
Mode group RESET DB11.DBX0.7 DB3000.DBX0.7
Machine function teach in DB11.DBX1.0 DB3000.DBX1.0
Machine function REPOS DB11.DBX1.1 -
Machine function REF DB11.DBX1.2 DB3000.DBX1.2
Signal name SINUMERIK 840D sl SINUMERIK 828D
Selected mode AUTOMATIC DB11.DBX4.0 -
Selected mode MDI DB11.DBX4.1 -
Selected JOG mode DB11.DBX4.2 -
Selected machine function teach in DB11.DBX5.0 -
Selected machine function REPOS DB11.DBX5.1 -
Selected machine function REF DB11.DBX5.2 -
Active mode AUTOMATIC DB11.DBX6.0 DB3100.DBX0.0
Active mode MDI DB11.DBX6.1 DB3100.DBX0.1
Active mode JOG DB11.DBX6.2 DB3100.DBX0.2
Mode group ready DB11.DBX6.3 DB3100.DBX0.3
Mode group has been reset DB11.DBX6.4 -
NCK internal JOG active DB11.DBX6.5 -
All channels in the reset state DB11.DBX6.7 -
Active machine function teach in DB11.DBX7.0 DB3100.DBX1.0
Active machine function REPOS DB11.DBX7.1 -
Active machine function REF DB11.DBX7.2 DB3100.DBX1.2
