Siemens SINUMERIK 828D Function Manual

G2: Velocities, setpoint / actual value systems, closed-loop control
7.7 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
389
7.7.1.4 Axis/spindlespecific machine data
Number Identifier: $MA_ Description
30110 CTRLOUT_MODULE_NR Setpoint assignment: Drive number
30120 CTRLOUT_NR Setpoint assignment: Setpoint output on drive module
30130 CTRLOUT_TYPE Output type of setpoint
30200 NUM_ENCS Number of encoders
30220 ENC_MODULE_NR Actual value assignment: Drive module number
30230 ENC_INPUT_NR Actual value assignment: Input on the drive module
30240 ENC_TYPE Type of actual-value acquisition (position actual value)
30242 ENC_IS_INDEPENDENT Encoder is independent
30300 IS_ROT_AX Rotary axis
31000 ENC_IS_LINEAR Direct measuring system (linear scale)
31010 ENC_GRID_POINT_DIST Distance between reference marks on linear scales
31020 ENC_RESOL Encoder pulses per revolution
31030 LEADSCREW_PITCH Leadscrew pitch
31040 ENC_IS_DIRECT Encoder is connected directly to the machine
31044 ENC_IS_DIRECT2 Encoder on intermediate gear
31050 DRIVE_AX_RATIO_DENOM Denominator load gearbox
31060 DRIVE_AX_RATIO_NUMERA Numerator load gearbox
31064 DRIVE_AX_RATIO2_DENOM Intermediate gear denominator
31066 DRIVE_AX_RATIO2_NUMERA Intermediate gear numerator
31070 DRIVE_ENC_RATIO_DENOM Measuring gear denominator
31080 DRIVE_ENC_RATIO_NUMERA Measuring gear numerator
31090 JOG_INCR_WEIGHT Weighting of increment for INC/handwheel
31200 SCALING_FACTOR_G70_G71 Factor for converting values when G70/G71 is active
32000 MAX_AX_VELO Maximum axis velocity
32100 AX_MOTION_DIR Travel direction
32110 ENC_FEEDBACK_POL Sign actual value (feedback polarity)
32200 POSCTRL_GAIN Servo gain factor (Kv)
32210 POSCTRL_INTEGR_TIME Integrator time position controller
32220 POSCTRL_INTEGR_ENABLE Activation of integral component of position controller
32250 RATED_OUTVAL Rated output voltage
32260 RATED_VELO Rated motor speed
32450 BACKLASH Backlash
32500 FRICT_COMP_ENABLE Friction compensation active
32610 VELO_FFW_WEIGHT Feedforward control factor for speed feedforward
control
32620 FFW_MODE Feedforward control mode
32630 FFW_ACTIVATION_MODE Activate feedforward control from program
32650 AX_INERTIA Moment of inertia for torque feedforward control
32652 AX_MASS Axis mass for torque precontrol
32711 CEC_SCALING_SYSTEM_METRIC System of measurement of sag compensation
