K1: Mode group, channel, program operation, reset response
9.17 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
679
9.17.3.4 Signals to NC
9.17.3.5 Signals from channel
Signal name SINUMERIK 840D sl SINUMERIK 828D
Activate DRF DB21, ... .DBX0.3 DB3200.DBX0.3
Activate single block DB21, ... .DBX0.4 DB3200.DBX0.4
Activate M01 DB21, ... .DBX0.5 DB3200.DBX0.5
Activate dry run feedrate DB21, ... .DBX0.6 DB3200.DBX0.6
PLC action completed DB21, ... .DBX1.6 -
Activate the program test DB21, ... .DBX1.7 DB3200.DBX1.7
Skip block levels: /0 to /7 DB21, ... .DBX2.0-7 DB3200.DBX2.0-7
Read-in disable DB21, ... .DBX6.1 DB3200.DBX6.1
Program level abort DB21, ... .DBX6.4 DB3200.DBX6.4
NC start disable DB21, ... .DBX7.0 DB3200.DBX7.0
NC start DB21, ... .DBX7.1 DB3200.DBX7.1
NC stop at block limit DB21, ... .DBX7.2 DB3200.DBX7.2
NC stop DB21, ... .DBX7.3 DB3200.DBX7.3
NC stop axes plus spindles DB21, ... .DBX7.4 DB3200.DBX7.4
Reset DB21, ... .DBX7.7 -
REPOSPATHMODE DB21, ... .DBX31.0-2 -
REPOSMODEEDGE DB21, ... .DBX31.4 -
Signal name SINUMERIK 840D sl SINUMERIK 828D
DRF selected DB21, ... .DBX24.3 DB1700.DBX0.3
Select NCK associated M01 DB21, ... .DBX24.4 -
M01 selected DB21, ... .DBX24.5 DB1700.DBX0.5
Dry run feedrate selected DB21, ... .DBX24.6 DB1700.DBX0.6
REPOSPATHMODE 0 - 2 DB21, ... .DBX25.0-2 -
Feedrate override selected for rapid traverse DB21, ... .DBX25.3 DB1700.DBX1.3
REPOS MODE EDGE DB21, ... .DBX25.4 -
Program test selected DB21, ... .DBX25.7 DB1700.DBX1.7
Skip-block selected /0 - /7 DB21, ... .DBX26.0-7 DB1700.DBX2.0-7
Skip-block selected /8 DB21, ... .DBX27.0 DB1700.DBX3.0
Skip-block selected /9 DB21, ... .DBX27.1 DB1700.DBX3.1
REPOSPATHMODE 0 - 2 DB21, ... .DBX31.0-2 -
REPOS MODE EDGE DB21, ... .DBX31.4 -
Skip block active /8 DB21, ... .DBX31.6 DB3200.DBX15.6
Skip block active /9 DB21, ... .DBX31.7 DB3200.DBX15.7
Execution from external active DB21, ... .DBX32.0 DB3300.DBX0.0
Action block active DB21, ... .DBX32.3 DB3300.DBX0.3
Approach block active DB21, ... .DBX32.4 DB3300.DBX0.4
M0/M1 active DB21, ... .DBX32.5 DB3300.DBX0.5
