K1: Mode group, channel, program operation, reset response
9.17 Data lists
Basic Functions
680 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Last action block active DB21, ... .DBX32.6 DB3300.DBX0.6
Block search active DB21, ... .DBX33.4 DB3300.DBX1.4
M02/M30 active DB21, ... .DBX33.5 DB3300.DBX1.5
Transformation active DB21, ... .DBX33.6 DB3300.DBX1.6
Program test active DB21, ... .DBX33.7 DB3300.DBX1.7
Program status: Running DB21, ... .DBX35.0 DB3300.DBX3.0
Program status: Maintaining DB21, ... .DBX35.1 DB3300.DBX3.1
Program status: Stopped DB21, ... .DBX35.2 DB3300.DBX3.2
Program status: Interrupted DB21, ... .DBX35.3 DB3300.DBX3.3
Program status: Aborted DB21, ... .DBX35.4 DB3300.DBX3.4
Channel status: Active DB21, ... .DBX35.5 DB3300.DBX3.5
Channel status: Interrupted DB21, ... .DBX35.6 DB3300.DBX3.6
Channel status: Reset DB21, ... .DBX35.7 DB3300.DBX3.7
Interrupt handling active DB21, ... .DBX36.4 -
Channel ready DB21, ... .DBX36.5 -
Read-in enable is ignored DB21, ... .DBX37.6 -
Stop at the end of block with SBL is suppressed DB21, ... .DBX37.7 -
Number of the active G function of G function group 1 – n
(8 bit int)
DB21, ... .DBB208-271 DB3500.DBB0-63
Workpiece setpoint reached DB21, ... .DBX317.2 DB3300.DBX4001.1
ASUB is stopped DB21, ... .DBX318.0 DB3300.DBX4002.0
Block search via program test is active DB21, ... .DBX318.1 -
REPOS MODE EDGEACKN DB21, ... .DBX319.0 -
Repos Path Mode Ackn: 0 - 2 DB21, ... .DBX319.1-3 -
Repos DEFERAL Chan DB21, ... .DBX319.5 -
Display of the triggering event in case of event-driven
program call
DB21, ... .DBX376.0-7 DB3300.DBB4004
ASUB is active DB21, ... .DBX378.0 DB3300.DBB4006.0
ASUB with suppressed display update is active DB21, ... .DBX378.1 DB3300.DBB4006.1
Signal name SINUMERIK 840D sl SINUMERIK 828D
