W1: Tool offset
18.16 Data lists
Basic Functions
1608 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
18.16 Data lists
18.16.1 Machine data
18.16.1.1 NC-specific machine data
18.16.1.2 Channelspecific machine data
Number Identifier: $MN_ Description
18082 MM_NUM_TOOL Number of tools that the NCK can manage (SRAM)
18088 MM_NUM_TOOL_CARRIER Maximum number of the defined toolholders
18094 MM_NUM_CC_TDA_PARAM Number of tool data (SRAM)
18096 MM_NUM_CC_TOA_PARAM Number of data, per tool cutting edge for compile
cycles (SRAM)
18100 MM_NUM_CUTTING_EDGES_IN_TOA Tool offsets in the TOA area (SRAM)
18102 MM_TYPE_OF_CUTTING_EDGE Type of D number programming (SRAM)
18105 MM_MAX_CUTTING_EDGE_NO Maximum value of D number
18106 MM_MAX_CUTTING_EDGE_PERTOOL Maximum number of D numbers per tool
18108 MM_NUM_SUMCORR Number of all sum offsets in NCK
18110 MM_MAX_SUMCORR_PER_CUTTEDGE Number of additive offsets per cutting edge
18112 MM_KIND_OF_SUMCORR Properties of additive offsets in the TO area (SRAM)
18114 MM_ENABLE_TOOL_ORIENT Assign orientation to cutting edges
18116 MM_NUM_TOOL_ENV Tool environments in the TOA area (SRAM)
Number Identifier: $MC_ Description
20096 T_M_ADDRESS_EXT_IS_SPINO Meaning of the address extension with T, M tool
change
20110 RESET_MODE_MASK Definition of initial control setting after RESET/part
program end
20120 TOOL_RESET_VALUE Tool length compensation at power-up (Reset/TP end)
20121 TOOL_PRESEL_RESET_VALUE Preselected tool on RESET
20125 CUTMOD_ERR Troubleshooting for the CUTMOD function
20126 TOOL_CARRIER_RESET_VALUE Active toolholder on RESET
20127 CUTMOD_INIT Initialize CUTMOD for POWERON
20130 CUTTING_EDGE_RESET_VALUE Tool cutting edge length compensation at power-up
(Reset/TP end)
20132 SUMCORR_RESET_VALUE Additive offset effective at RESET
20140 TRAFO_RESET_VALUE Transformation data record at power up (Reset/TP
end)
20180 TOCARR_ROT_ANGLE_INCR[i] Rotary axis increment of the toolholder with orientation
capability
20182 TOCARR_ROT_ANGLE_OFFSET[i] Rotary axis offset of toolholder with orientation
capability
