Siemens SINUMERIK 828D Function Manual

W1: Tool offset
18.5 Tool radius compensation 2D (TRC)
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1487
Figure 18-31 Bottleneck detection and outside corners
18.5.9 Blocks with variable compensation value
Supplementary conditions
A variable compensation value is permissible for all types of interpolation (including circular and spine
interpolation).
It is also permitted to change the sign (and, therefore, the compensation side).
Figure 18-32 Tool radius compensation with variable compensation value
2IIVHWFXUYHZKHQ',6&!
FRQLFVHFWLRQ
2IIVHWFXUYHZKHQ
',6& FLUFOH
7RROFHQWHUSDWK
3URJUDPPHGFRQWRXU
1
1
1
1
1

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
