P4: PLC for SINUMERIK 828D
14.6 Function interface
Basic Functions
1166 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
14.6.2.2 PI services
PI service ASUB
Initialization
With the ASUB PI service, it is possible to assign the interrupt numbers 1 and 2 fixed program names from the
PLC. Precondition for this is the existence of the programs
PLCASUP1_SPF
or
PLCASUP2_SPF
in the CMA
directory.
The following must be taken into account during the initialization:
• The PI service ASUB only has to be executed once after a restart and it is then kept.
• An initialization may only be performed when the channel is inactive.
• If a "power up" is configured as the initiating event for the events-triggered program call, initialization must
only be started after the end of the event-triggered program.
Relevant PI parameters for PI services 1 and 2
PI service LOGOUT
Reset password
The password last transferred to the NCK is reset.
Relevant PI parameters for PI service 3
None
PI index Function Interrupt priority
1 Assignment of Interrupt 1 to the CMA_DIR/
PLCASUP1_SPF program.
1
2 Assignment of Interrupt 2 to the CMA_DIR/
PLCASUP2_SPF program.
2
PI parameter Address Signal Valid values
1 DB1200.DBW4004 LIFTFAST 0/1
2 DB1200.DBW4006 BLSYNC 0/1
PI index Function
3 Reset password
