Siemens SINUMERIK 828D Function Manual

A2: Various NC/PLC interface signals and functions
1.5 Data lists
Basic Functions
70 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1.5.1.2 NC-specific machine data
1.5.1.3 Channelspecific machine data
9232 USER_BEGIN_WRITE_RPA_1 Start of the first RPA area
9233 USER_END_WRITE_RPA_1 End of the first RPA area
9234 USER_CLASS_WRITE_RPA_2 Write protection for second RPA area
9235 USER_BEGIN_WRITE_RPA_2 Start of the second RPA area
9236 USER_END_WRITE_RPA_2 End of the second RPA area
9237 USER_CLASS_WRITE_RPA_3 Write protection for third RPA area
9238 USER_BEGIN_WRITE_RPA_3 Start of the third RPA area
9239 USER_END_WRITE_RPA_3 End of the third RPA area
9240 USER_CLASS_WRITE_TOA_NAME Change tool designation and duplo
9241 USER_CLASS_WRITE_TOA_Type Change tool type
9510 USER_CLASS_DIRECTORY1_P Protection level for network drive 1 for
PROGRAM operating area
9511 USER_CLASS_DIRECTORY2_P Protection level for network drive 2 for
PROGRAM operating area
9512 USER_CLASS_DIRECTORY3_P Protection level for network drive 3 for
PROGRAM operating area
9513 USER_CLASS_DIRECTORY4_P Protection level for network drive 4 for
PROGRAM operating area
9516 USER_CLASS_DIRECTORY1_M Protection level for network drive 1 for
MACHINE operating area
9517 USER_CLASS_DIRECTORY2_M Protection level for network drive 2 for
MACHINE operating area
9518 USER_CLASS_DIRECTORY3_M Protection level for network drive 3 for
MACHINE operating area
9519 USER_CLASS_DIRECTORY4_M Protection level for network drive 4 for
MACHINE operating area
Number Identifier: $MN_ Description
10350 FASTIO_DIG_NUM_INPUTS Number of active digital NCK input bytes
10360 FASTIO_DIG_NUM_OUTPUTS Number of active digital NCK output bytes
10361 FASTIO_DIG_SHORT_CIRCUIT Short-circuit digital inputs and outputs
11120 LUD_EXTENDED_SCOPE Activate programglobal variables (PUD)
11270 DEFAULT_VALUES_MEM_MSK Activ.
Function: Save DEFAULT values of GUD.
18150 MM_GUD_VALUES_MEM Reserve memory space for GUD
Number Identifier: $MC_ Description
21015 INVOLUTE_RADIUS_DELTA NC start disable without reference point
21016 INVOLUTE_AUTO_ANGLE_LIMIT Automatic angle limitation for involute interpolation
Number
Identifier: $MM_ Description
SINUMERIK Operate

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
