G2: Velocities, setpoint / actual value systems, closed-loop control
7.7 Data lists
Basic Functions
388 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
7.7 Data lists
7.7.1 Machine data
7.7.1.1 Displaying machine data
7.7.1.2 NC-specific machine data
7.7.1.3 Channelspecific machine data
Number Identifier: $MM_ Description
9004 DISPLAY_RESOLUTION Display resolution
9010 SPIND_DISPLAY_RESOLUTION Display resolution for spindles
9011 DISPLAY_RESOLUTION_INCH Display resolution for INCH system of measurement
Number Identifier: $MN_ Description
10000 AXCONF_MACHAX_NAME_TAB Machine axis name
10050 SYSCLOCK_CYCLE_TIME System basic cycle
10070 IPO_SYSCLOCK_TIME_RATIO Factor for interpolator cycle
10060 POSCTRL_SYSCLOCK_TIME_RATIO Factor for position-control cycle
10200 INT_INCR_PER_MM Computational resolution for linear positions
10210 INT_INCR_PER_DEG Computational resolution for angular positions
10220 SCALING_USER_DEF_MASK Activation of scaling factors
10230 SCALING_FACTORS_USER_DEF Scaling factors of physical quantities
10240 SCALING_SYSTEM_IS_METRIC Basic system metric
10250 SCALING_VALUE_INCH Conversion factor for switchover to
inch system
10260 CONVERT_SCALING_SYSTEM Basic system switchover active
10270 POS_TAB_SCALING_SYSTEM Measuring system of position tables
10290 CC_TDA_PARAM_UNIT Physical units of the tool data for CC
10292 CC_TOA_PARAM_UNIT Physical units of the tool edge data for CC
13050 DRIVE_LOGIC_ADDRESS Logical drive addresses
13060 DRIVE_TELEGRAM_TYPE Standard message frame type for PROFIBUS DP
13070 DRIVE_FUNCTION_MASK DP function used
13080 DRIVE_TYPE_DP Drive type PROFIBUS DP
Number Identifier: $MC_ Description
20150 GCODE_RESET_VALUES Initial setting of the G groups
