P4: PLC for SINUMERIK 828D
14.4 Test and diagnostic functions
Basic Functions
1140 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
14.4.3.2 Open status chart
Open a status chart to evaluate or change the contents of the chart.
Procedure
•Click on the button "Status chart" in the navigation bar.
or
• Select the menu command "View" > "Status chart".
or
• Open the directory of the status chart in the operation tree and double click on the symbol of a chart.
• If your project includes more than one status chart, using the tab for the status charts at the lower edge of the
window, you can switch over between the individual charts:
14.4.3.3 Working with several status charts
Inserting additional additional status charts
To insert additional status charts:
• In the operation tree, right click on the "Status chart" folder and in the pop-up menu, select the command
"Insert status chart".
or
• Open the window "Status chart" and call the "Edit" menu of right click and select the command "Insert
contents" > "Table".
Switching between the status charts
After you have inserted a new status chart, a new tab is displayed at the lower edge of the window "Status chart":
If you wish to switch between the status tables:
• Click on the tab of the required status chart.
Note
If you open a status chart, then the status is still not displayed. You must enable the status
chart so that the status information is updated (see "Enabling the status table [Page 1144]").
