Siemens SINUMERIK 828D Function Manual

K1: Mode group, channel, program operation, reset response
9.17 Data lists
Basic Functions
674 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
9.17.1.2 Channelspecific machine data
Basic machine data
11620 PROG_EVENT_NAME Program name for PROG_EVENT
11717 D_NO_FCT_CYCLE_NAME Subroutine name for D function replacement
15700 LANG_SUB_NAME Name for replacement subroutine
15702 LANG_SUB_PATH Call path for replacement subroutine
17200 GMMC_INFO_NO_UNIT Global HMI info (without physical unit)
17201 GMMC_INFO_NO_UNIT_STATUS Global HMI status info (without physical unit)
18360 MM_EXT_PROG_BUFFER_SIZE FIFO buffer size for execution from external source
(DRAM)
18362 MM_EXT_PROG_NUM Number of program levels that can be processed
simultaneously from external
Number Identifier: $MC_ Description
20000 CHAN_NAME Channel name
20050 AXCONF_GEOAX_ASSIGN_TAB Assignment of geometry axis to channel axis
20060 AXCONF_GEOAX_NAME_TAB Geometry axis name in channel
20070 AXCONF_MACHAX_USED Machine axis number valid in channel
20080 AXCONF_CHANAX_NAME_TAB Channel axis name in channel [channel axis no.]: 0...7
20090 SPIND_DEF_MASTER_SPIND Initial setting of master spindle in channel
20100 DIAMETER_AX_DEF Geometry axis with transverse axis function
20106 PROG_EVENT_IGN_SINGLEBLOCK Prog events ignore the single block
20107 PROG_EVENT_IGN_INHIBIT Prog events ignore the read-in disable
20108 PROG_EVENT_MASK Eventdriven program calls
20109 PROG_EVENT_MASK_PROPERTIES Prog events properties
20114 MODESWITCH_MASK Setting for REPOS
20116 IGNORE_INHIBIT_ASUP Execute user ASUBs completely in spite of readin
disable
20117 IGNORE_SINGLEBLOCK_ASUP Process user ASUBs completely in spite of single-
block processing
20160 CUBIC_SPLINE_BLOCKS Number of blocks for C spline
20170 COMPRESS_BLOCK_PATH_LIMIT Maximum traversing length of NC block for
compression
20191 IGN_PROG_STATE_ASUP Do not display the execution of the interrupt routine on
the operator panel
20192 PROG_EVENT_IGN_PROG_STATE Do not display the execution of the program events on
the operator panel
20193 PROG_EVENT_IGN_STOP Prog events ignore the Stop key
20210 CUTCOM_CORNER_LIMIT Max. angle for intersection calculation with tool radius
compensation
20220 CUTCOM_MAX_DISC Maximum value for DISC
Number Identifier: $MN_ Description
