K1: Mode group, channel, program operation, reset response
9.17 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
675
Block search
Reset response
20230 CUTCOM_CURVE_INSERT_LIMIT Maximum angle for intersection calculation with tool
radius compensation
20240 CUTCOM_MAXNUM_CHECK_BLOCKS Blocks for predictive contour calculation with tool
radius compensation
20250 CUTCOM_MAXNUM_DUMMY_BLOCKS Maximum number of blocks without traversing motion
for TRC
20270 CUTTING_EDGE_DEFAULT Basic setting of tool cutting edge without programming
20400 LOOKAH_USE_VELO_NEXT_BLOCK Look Ahead to programmed following block velocity
20430 LOOKAH_NUM_OVR_POINTS Number of override corner values for Look Ahead
20440 LOOKAH_OVR_POINTS Override switch points for LookAhead
20500 CONST_VELO_MIN_TIME Minimum time with constant velocity
20600 MAX_PATH_JERK Pathrelated maximum jerk
20610 ADD_MOVE_ACCEL_RESERVE Acceleration reserve for overlaid movements
20700 REFP_NC_START_LOCK NC start disable without reference point
20750 ALLOW_GO_IN_G96 G0 logic for G96, G961
20800 SPF_END_TO_VDI Subprogram end to PLC
21000 CIRCLE_ERROR_CONST Circle end point monitoring constant
21010 CIRCLE_ERROR_FACTOR Circle end point monitoring factor
21100 ORIENTATION_IS_EULER Angle definition for orientation programming
21110 X_AXIS_IN_OLD_X_Z_PLANE Coordinate system for automatic Frame definition
21200 LIFTFAST_DIST Traversing path for fast retraction from the contour
21210 SETINT_ASSIGN_FASTIN HW assignment of the ext. NCK input byte for NC
program interrupt:
21202 LIFTFAST_WITH_MIRROR Lift fast with mirror
Number Identifier: $MC_ Description
20128 COLLECT_TOOL_CHANGE Tool change commands to the PLC after block search
22600 SERUPRO_SPEED_MODE Velocity with block search type 5
22601 SERUPRO_SPEED_FACTOR Velocity factor for block search type 5
22621 ENABLE_START_MODE_MASK_PRT Switches MD22620: START_MODE_MASK_ PRT for
SERUPRO search run
22622 DISABLE_PLC_START Allow part program start via PLC
22680 AUTO_IPTR_LOCK Disable interrupt pointer
Number Identifier: $MC_ Description
20110 RESET_MODE_MASK Initial setting after RESET / parts program end
20112 START_MODE_MASK Basic setting for NC start after part program start
20118 GEOAX_CHANGE_RESET Allow automatic geometry axis change
Number Identifier: $MC_ Description
