K1: Mode group, channel, program operation, reset response
9.17 Data lists
Basic Functions
676 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Auxiliary function settings
Memory settings
20120 TOOL_RESET_VALUE Tool length compensation when powering-up
(RESET/part program end)
20121 TOOL_PRESEL_RESET_VALUE Preselected tool on RESET
20130 CUTTING_EDGE_RESET_VALUE Tool cutting edge length compensation when
powering-up (RESET/part program end)
20140 TRAFO_RESET_VALUE Transformation data set when powering-up (RESET/
part program end)
20150 GCODE_RESET_VALUES Initial setting of the G groups
20152 GCODE_RESET_MODE Reset behavior of G groups
20156 MAXNUM_GCODES_EXT Reset behavior of the external G groups
22620 START_MODE_MASK_PRT Initial setting at special NC Start after power-up and at
RESET
Number Identifier: $MC_ Description
22000 AUXFU_ASSIGN_GROUP Auxiliary function group
22010 AUXFU_ASSIGN_TYPE Auxiliary function type
22020 AUXFU_ASSIGN_EXTENSION Auxiliary function extension
22030 AUXFU_ASSIGN_VALUE Auxiliary function value
22200 AUXFU_M_SYNC_TYPE Output timing of M functions
22210 AUXFU_S_SYNC_TYPE Output timing of S functions
22220 AUXFU_T_SYNC_TYPE Output timing of T functions
22230 AUXFU_H_SYNC_TYPE Output timing of H functions
22240 AUXFU_F_SYNC_TYPE Output timing of F functions
22250 AUXFU_D_SYNC_TYPE Output timing of D functions
22400 S_VALUES_ACTIVE_AFTER_RESET S function active after RESET
22410 F_VALUES_ACTIVE_AFTER_RESET F function active after RESET
22510 GCODE_GROUPS_TO_PLC G codes that are output to the NCK/PLC interface on
block change/RESET
22550 TOOL_CHANGE_MODE New tool offset for M function
22560 TOOL_CHANGE_M_CODE M function for tool change
Number Identifier: $MC_ Description
27900 REORG_LOG_LIMIT Percentage of IPO buffer for log file enable
28000 MM_REORG_LOG_FILE_MEM Memory size for REORG (DRAM)
28010 MM_NUM_REORG_LUD_MODULES Number of blocks for local user variables for REORG
28020 MM_NUM_LUD_NAMES_TOTAL Number of local user variables (DRAM)
28040 MM_LUD_VALUES_MEM Memory size for local user variables (DRAM)
28050 MM_NUM_R_PARAM Number of channelspecific R parameters (SRAM)
Number Identifier: $MC_ Description
