Siemens SINUMERIK 828D Function Manual

A2: Various NC/PLC interface signals and functions
1.5 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
69
1.5 Data lists
1.5.1 Machine data
1.5.1.1 Display machine data
Number
Identifier: $MM_ Description
SINUMERIK Operate
9000 LCD_CONTRAST Contrast
9001 DISPLAY_TYPE Monitor type
9004 DISPLAY_RESOLUTION Display resolution
9008 KEYBOARD_TYPE Keyboard type (0: OP, 1: MFII/QWERTY)
9009 KEYBOARD_STATE Shift behavior of keyboard during booting
9010 SPIND_DISPLAY_RESOLUTION Display resolution for spindle values
9011 DISPLAY_RESOLUTION_INCH Display resolution for INCH_system of units
9012 ACTION_LOG_MODE Set action mode for action log
9020 TECHNOLOGY Basic configuration for simulation and free
contour programming
9200 USER_CLASS_READ_TOA Protection level read tool offsets general
9201 USER_CLASS_WRITE_TOA_GEO Protection level write tool geometry
9202 USER_CLASS_WRITE_TOA_WEAR Protection level write tool wear data
9203 USER_CLASS_WRITE_FINE Protection level write fine
9204 USER_CLASS_WRITE_TOA_SC Protection level change total tool offsets
9205 USER_CLASS_WRITE_TOA_EC Protection level change tool setup offsets
9206 USER_CLASS_WRITE_TOA_SUPVIS Protection level change tool-monitoring limit
values
9207 USER_CLASS_WRITE_TOA_ASSDNO Change D No. assigned to a tool edge
9208 USER_CLASS_WRITE_MAG_WGROUP change wear group magazine location/mag.
9209 USER_CLASS_WRITE_TOA_ADAPT Protection level write tool adapter data
9210 USER_CLASS_WRITE_ZOA Protection level write settable zero offset
9211 USER_CLASS_READ_GUD_LUD Protection level read user variables
9212 USER_CLASS_WRITE_GUD_LUD Protection level write user variables
9213 USER_CLASS_OVERSTORE_HIGH Protection level extended overstore
9214 USER_CLASS_WRITE_PRG_CONDIT Protection level program control
9215 USER_CLASS_WRITE_SEA Protection level write setting data
9218 USER_CLASS_SELECT_PROGRAM Protection level part program selection
9219 USER_CLASS_TEACH_IN Protection level TEACH IN
9220 USER_CLASS_PRESET Protection level PRESET
9221 USER_CLASS_CLEAR_RPA Protection level delete R parameters
9222 USER_CLASS_WRITE_RPA Protection level write R parameters
9231 USER_CLASS_WRITE_RPA_1 Write protection for first RPA area

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
