Siemens SINUMERIK 828D Function Manual

P4: PLC for SINUMERIK 828D
14.6 Function interface
Basic Functions
1196 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
14.6.5.1 The ASUB UP interface
Job start
INT1 start, INT2 start
1: Starts the execution of the ASUB, which is assigned to the INT in question.
0: Reset to 0 for acknowledgement input in the result interface
Job result
DB3400 ASUB: Job [r/w]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBB 0000 INT1 start
DBB 0001 INT2 start
DBB 0002
DBB 0003
DB3400 ASUB: Result [r]
PLC -> NCK interface
Byte Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
DBB 1000 INT1
ASUB
cannot be
executed
Interrupt
No. not
allocated
ASUB is
being
executed
ASUB
completed
DBB 1001 INT2
ASUB
cannot be
executed
Interrupt
No. not
allocated
ASUB is
being
executed
ASUB
completed
DBB 1002
DBB 2003

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
