Siemens SINUMERIK 828D Function Manual

A2: Various NC/PLC interface signals and functions
1.5 Data lists
Basic Functions
74 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1.5.3.6 Signals from channel
1.5.3.7 Signals to axis/spindle
1.5.3.8 Signals from axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Channelspecific NCK alarm is active DB21, ... .DBX36.6 DB3300.DBX4.6
NCK alarm with processing stop present DB21, … .DBX36.7 DB3300.DBX4.7
Overstore active DB21, ... .DBX318.7 -
Signal name SINUMERIK 840D sl SINUMERIK 828D
Axis/spindle disable DB31, ... .DBX1.3 DB380x.DBX1.3
Follow-up mode DB31, ... .DBX1.4 DB380x.DBX1.4
Position measuring system 1 DB31, ... .DBX1.5 DB380x.DBX1.5
Position measuring system 2 DB31, ... .DBX1.6 DB380x.DBX1.6
Controller enable DB31, ... .DBX2.1 DB380x.DBX2.1
Delete distancetogo (axisspecific)/Spindle reset DB31, ... .DBX2.2 DB380x.DBX2.2
Parameter set selection A, B, C DB31, ... .DBX21.0-2 DB380x.DBX4001.0-2
Motor selection A, B DB31, ... .DBX21.4 -
Motor being selected DB31, ... .DBX21.5 -
Speed controller integrator disable DB31, ... .DBX21.6 DB380x.DBX4001.6
Pulse enable DB31, ... .DBX21.7 DB380x.DBX4001.7
Signal name SINUMERIK 840D sl SINUMERIK 828D
Referenced, synchronized 1 /
Referenced, synchronized 2
DB31, ... .DBX60.4/5 DB390x.DBX0.4/5
Traverse command minus / plus DB31, ... .DBX64.6/7 DB390x.DBX4.6/7
Followup mode active DB31, ... .DBX61.3 DB390x.DBX1.3
Axis/spindle stationary (n < n
min
) DB31, ... .DBX61.4 DB390x.DBX1.4
Position controller active DB31, ... .DBX61.5 DB390x.DBX1.5
Speed controller active DB31, ... .DBX61.6 DB390x.DBX1.6
Current controller active DB31, ... .DBX61.7 DB390x.DBX1.7
Lubrication pulse DB31, ... .DBX76.0 DB390x.DBX1002.0
Active drive parameter set A, B, C DB31, ... .DBX93.0-2 DB390x.DBX4001.0-2
Active motor A, B DB31, ... .DBX93.3/4 -
Drive Ready DB31, ... .DBX93.5 DB390x.DBX4001.5
Speed controller integrator disabled DB31, ... .DBX93.6 DB390x.DBX4001.6
Pulses enabled DB31, ... .DBX93.7 DB390x.DBX4001.7
Motor temperature prewarning DB31, ... .DBX94.0 DB390x.DBX4002.0
Heatsink temperature prewarning DB31, ... .DBX94.1 DB390x.DBX4002.1
Ramp-up completed DB31, ... .DBX94.2 DB390x.DBX4002.2
|M
d
| < M
dx
DB31, ... .DBX94.3 DB390x.DBX4002.3
