Siemens SINUMERIK 828D Function Manual

P4: PLC for SINUMERIK 828D
14.1 Overview
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1091
14.1.4 PLC I/O, fast onboard inputs/outputs
For information on the I/O modules, the machine control panels as well as the assignment of the onboard inputs/
outputs to the PLC, see:
References:
Manual PPU SINUMERIK 828D
14.1.5 PLC Toolbox
14.1.5.1 Star/delta changeover
For star/delta changeover, the following block is provided in the PLC Toolbox:
•StarDelta
Note
This block can be used to perform a star/delta changeover - also for 1PH8 spindle motors
with SMI connected to a SINAMICS S120.

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
