V1: Feedrates
17.7 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1417
17.7.3 Signals
17.7.3.1 Signals to channel
17.7.3.2 Signals from channel
17.7.3.3 Signals to axis/spindle
Signal name SINUMERIK 840D sl SINUMERIK 828D
Activate dry run feedrate DB21, ... .DBX0.6 DB3200.DBX0.6
Feedrate override DB21, ... .DBB4 DB3200.DBB4
Rapid traverse override DB21, ... .DBB5 DB3200.DBB5
Feed disable DB21, ... .DBX6.0 DB3200.DBX6.0
Rapid traverse override active DB21, ... .DBX6.6 DB3200.DBX6.6
Feedrate override active DB21, ... .DBX6.7 DB3200.DBX6.7
Feed stop, geometry axis 1 DB21, ... .DBX12.3 DB3200.DBX1000.3
Feed stop, geometry axis 2 DB21, ... .DBX16.3 DB3200.DBX1004.3
Feed stop, geometry axis 3 DB21, ... .DBX20.3 DB3200.DBX1008.3
Signal name SINUMERIK 840D sl SINUMERIK 828D
Dry run feedrate selected DB21, ... .DBX24.6 DB1700.DBX0.6
Feedrate override for rapid traverse selected DB21, ... .DBX25.3 DB1700.DBX1.3
Activate fixed feedrate 1 for path/geometry axes DB21, ... .DBX29.0 -
Activate fixed feedrate 2 for path/geometry axes DB21, ... .DBX29.1 -
Activate fixed feedrate 3 for path/geometry axes DB21, ... .DBX29.2 -
Activate fixed feedrate 4 for path/geometry axes DB21, ... .DBX29.3 -
Dry run feedrate active DB21, ... .DBX318.6 DB3300.DBX4002.6
Signal name SINUMERIK 840D sl SINUMERIK 828D
Feed/spindle override DB31, ... .DBB0 DB380x.DBB0
Override active DB31, ... .DBX1.7 DB380x.DBX1.7
Activate fixed feedrate 1 for machine axis DB31, ... .DBX3.2 -
Activate fixed feedrate 2 for machine axis DB31, ... .DBX3.3 -
Activate fixed feedrate 3 for machine axis DB31, ... .DBX3.4 -
Activate fixed feedrate 4 for machine axis DB31, ... .DBX3.5 -
Feed stop/spindle stop DB31, ... .DBX4.3 DB380x.DBX4.3
