K1: Mode group, channel, program operation, reset response
9.8 Block search Type 5 SERUPRO
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
557
Additional variable for interpretation during simulation search
In JOG and MDA modes, NC variable "selectedWorkPProg" can be used to select whether the previously
selected program or the program to be simulated is to be displayed in the HMI during the simulation, e.g., with
SERUPRO. For more information, refer to
References: /LIS2/ Lists (Book 2), Section "Variables".
9.8.10 Restrictions
Conditional use
SERUPRO supports the following NC functions subject to certain restrictions:
NCK functionality Restrictions
Master/slave for drives
and SERUPRO
Selective enabling and disabling of the master/slave link with
MASLON active
Axis enables and SERUPRO Real servo enable missing during program testing
Axis replacement and SERUPRO Axes traversing as path axes before RELEASE are ignored on
REPOS
