G2: Velocities, setpoint / actual value systems, closed-loop control
7.7 Data lists
Basic Functions
390 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
32800 EQUIV_CURRCTRL_TIME Equivalent time constant current control loop for
feedforward control
32810 EQUIV_SPEEDCTRL_TIME Equivalent time constant speed control loop for
feedforward control
32900 DYN_MATCH_ENABLE Dynamics matching
32910 DYN_MATCH_TIME [n] Time constant for dynamic response adaptation
32930 POSCTRL_OUT_FILTER_ENABLE Activation of low-pass filter at position controller output
33000 FIPO_TYPE Fine interpolator type
34320 ENC_INVERS[n] Length measuring system is inverse
35100 SPIND_VELO_LIMIT Maximum spindle speed
36200 AX_VELO_LIMIT [n] Threshold value for velocity monitoring
36210 CTRLOUT_LIMIT[n] Maximum speed setpoint
36400 AX_JERK_ENABLE Axial jerk limitation
36410 AX_JERK_TIME Time constant for axial jerk filter
36500 ENC_CHANGE_TOL Max. tolerance for position actual-value switchover
36510 ENC_DIFF_TOL Measuring system synchronism tolerance
36700 ENC_COMP_ENABLE[n] Interpolatory compensation
Number Identifier: $MA_ Description
