Call example:
Function 3, 4: Rapid data exchange PLC-NCK
FUNCTION FC 100 : VOID
VAR_TEMP
myAny: ANY ;
END_VAR
BEGIN
NETWORK
//Deactivate synchronized actions with ID3, ID10 and ID31 in NC channel 1 :
SYAK: OPEN DB21;
SET;
S DBX 300.2; //ID3
S DBX 301.1; //ID10
S DBX 303.6; //ID31
L B#16#1;
T MB11;
SPA TRAN;
//Synchronized actions from NCK channel 1:
SYVK: L B#16#2;
T MB11;
TRAN: CALL FC 21 (
Enable := M 10.0, //if TRUE, FC 21 active
Funct := MB 11,
S7Var := #myAny, //Not used
IVAR1 := 1, //Channel no.
IVAR2 := 0,
Error := M 10.1,
ErrCode := MW 12);
END_FUNCTION
