Siemens SINUMERIK 828D Function Manual

P4: PLC for SINUMERIK 828D
14.3 Programming
Basic Functions
1124 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
4. Select one of the following options in the message window "Load into CPU":
- "Bring target system into the stop condition"
→ If structurally modified programs or initial values of data blocks are to be loaded into the target system.
or
- "Load in the RUN operating state"
→ If neither program nor data block structures have changed.
The following message must be output after loading:
5. Confirm this message.
6.After "Loading in stop condition" – if required – switch the control back to RUN.
