P4: PLC for SINUMERIK 828D
14.6 Function interface
Basic Functions
1194 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
101 16#65 Programmed speed is too high
102 16#66 False value range, constant cutting rate (corresponds to MMC alarm 14840)
104 16#68 Following spindle: illegal programming (corresponds to alarm number 22030)
105 16#69 No measuring system available (corresponds to alarm number 16770)
106 16#6a Positioning process of the axis still active (corresponds to alarm number 22052)
107 16#6b Reference mark not found (corresponds to alarm number 22051)
108 16#6c No transition from speed control to position control (corresponds to alarm number 22050)
109 16#6d Reference mark not found (corresponds to alarm number 22051)
110 16#6e Velocity/speed is negative
111 16#6f Setpoint speed is zero
112 16#70 Invalid gear stage
115 16#73 Programmed position was not reached
117 16#75 G96/G961 is not active in the NC
118 16#76 G96/G961 is still active in the NC
120 16#78 Axis is not an indexing axis (corresponds to MMC alarm 20072)
121 16#79 Indexing position error (corresponds to MMC alarm 17510)
125 16#7d DC (shortest distance) not possible (corresponds to MMC alarm 16800)
126 16#7e Absolute value minus not possible (corresponds to MMC alarm 16820)
127 16#7f Absolute value plus not possible (corresponds to MMC alarm 16810)
128 16#80 No transverse axis available for diameter programming (corresponds to MMC alarm 16510)
130 16#82 Software end switch plus (corresponds to MMC alarm 20070)
131 16#83 Software end switch minus (corresponds to MMC alarm 20070)
132 16#84 Working area limit plus (corresponds to MMC alarm 20071)
133 16#85 Working area limit minus (corresponds to MMC alarm 20071)
134 16#85 Frame not permitted for indexing axis
135 16#87 Indexing axis with "Hirth toothing" is active (corresponds to MMC alarm 17501)
136 16#88 Indexing axis with "Hirth toothing" is active and axis not referenced (corresponds to MMC alarm
17503)
137 16#89 Spindle operation not possible for transformed spindle/axis (corresponds to MMC alarm 22290)
138 16#8A for the axis the corresponding effective coordinate-system-specific working area limit plus violated
(corresponds to MMC alarm 20082)
139 16#8B for the axis the corresponding effective coordinate-system-specific working area limit minus violated
(corresponds to MMC alarm 20082)
System or other serious interrupts:
200 16#c8 Corresponds to system alarm number 450007
Status Meaning
