Siemens SINUMERIK 828D Function Manual

R1: Reference point approach
15.6 Referencing with distancecoded reference marks
Basic Functions
1228 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
MD30340 $MA_MODULO_RANGE_START (starting position of modulo range)
Note
The reference point position is mapped onto the assigned (ghost) modulo range even with
axis function "Determination of reference point position rotary, distance-coded encoder within
the configured modulo range":
MD30455 $MA_MISC_FUNCTION_MASK (axis functions), BIT1 = 1

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
