Siemens SINUMERIK 828D Function Manual

S1: Spindles
16.4 Configurable gear adaptation
Basic Functions
1324 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Example
Gear stage change in DryRun
; 1. Activate 1st gear stage for output state
N00 M3 S1000 M41 ; 1st gear stage is selected
M0 ; Part program stops
; PI service: Activate dry run feedrate (DryRun)
; (Configuring)
N10 M42 ;
2nd gear stage requested, no gear stage change
takes place
N11 G0 X0 Y0 Z0 ; Positioning axes
N12 M0 ; Part program stops
; PI service: Deactivate dry run feedrate (DryRun)
; REORG and REPOS are performed
;
now the gear stage change to the 2nd gear stage
takes place
N20 G1 Z100 F1000
...
N99 M30 ; Part program end

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
