Siemens SINUMERIK 828D Function Manual

S1: Spindles
16.11 Data lists
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1359
32810 EQUIV_SPEEDCTRL_TIME Equivalent time constant speed control circuit for
feedforward control
32910 DYN_MATCH_TIME Time constant for dynamic matching
34040 REFP_VELO_SEARCH_MARKER Reference point creep speed
34060 REFP_MAX_MARKER_DIST Monitoring of zero mark distance
34080 REFP_MOVE_DIST Reference point distance/destination point for
distancecoded system
34090 REFP_MOVE_DIST_CORR Reference point offset/absolute offset, distancecoded
34100 REFP_SET_POS Reference point value
34200 ENC_REFP_MODE Homing mode
35000 SPIND_ASSIGN_TO_MACHAX Assignment of spindle to machine axis
35010 GEAR_STEP_CHANGE_ENABLE Type of gear step change
35012 GEAR_STEP_CHANGE_POSITION Gear step change position
35014 GEAR_STEP_USED_IN_AXISMODE Gear step for axis mode with M70
35020 SPIND_DEFAULT_MODE Basic spindle setting
35030 SPIND_DEFAULT_ACT_MASK Activate initial spindle setting
35035 SPIND_FUNCTION_MASK Setting of spindle-specific functions
35040 SPIND_ACTIVE_AFTER_RESET Spindle active after reset
35090 NUM_GEAR_STEPS Number of installed gear steps
35092 NUM_GEAR_STEPS2 2nd gear step data set: Number of installed gear steps
35100 SPIND_VELO_LIMIT Maximum spindle speed
35110 GEAR_STEP_MAX_VELO[n] Maximum speed for automatic gear stage change
35112 GEAR_STEP_MAX_VELO2[n] 2nd gear step data set: Maximum speed for automatic
gear stage change
35120 GEAR_STEP_MIN_VELO[n] Minimum speed for automatic gear stage change
35122 GEAR_STEP_MIN_VELO2[n] 2nd gear step data set: Minimum speed for automatic
gear stage change
35130 GEAR_STEP_MAX_VELO_LIMIT[n] Maximum speed of gear step
35135 GEAR_STEP_PC_MAX_VELO_LIMIT[n] Maximum speed of gear step in position control
35140 GEAR_STEP_MIN_VELO_LIMIT[n] Minimum speed of gear step
35150 SPIND_DES_VELO_TOL Spindle speed tolerance
35160 SPIND_EXTERN_VELO_LIMIT Spindle speed limitation via PLC
35200 GEAR_STEP_SPEEDCTRL_ACCEL[n] Acceleration in speed control mode
35210 GEAR_STEP_POSCTRL_ACCEL[n] Acceleration in position control mode
35212 GEAR_STEP_POSCTRL_ACCEL2[n] 2nd gear step data set: Acceleration in position control
mode
35220 ACCEL_REDUCTION_SPEED_POINT Speed limit for reduced acceleration
35230 ACCEL_REDUCTION_FACTOR Reduced acceleration
35300 SPIND_POSCTRL_VELO position control activation speed
35350 SPIND_POSITIONING_DIR Positioning direction of rotation for a nonsynchronized
spindle
35400 SPIND_OSCILL_DES_VELO Oscillation speed
Number Identifier: $MA_ Description

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
