Siemens SINUMERIK 828D Function Manual

S1: Spindles
16.11 Data lists
Basic Functions
1362 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Axis/spindle stationary (n < n
min
) DB31, ... .DBX61.4 DB390x.DBX1.4
Position controller active DB31, ... .DBX61.5 DB390x.DBX1.5
Speed controller active DB31, ... .DBX61.6 DB390x.DBX1.6
Current controller active DB31, ... .DBX61.7 DB390x.DBX1.7
Restored 1 DB31, ... .DBX71.4 -
Restored 2 DB31, ... .DBX71.5 -
Setpoint gear stage A to C DB31, ... .DBX82.0-2 DB390x.DBX2000.0-2
Change gear DB31, ... .DBX82.3 DB390x.DBX2000.3
Speed limit exceeded DB31, ... .DBX83.0 DB390x.DBX2001.0
Setpoint speed limited DB31, ... .DBX83.1 DB390x.DBX2001.1
Setpoint speed increased DB31, ... .DBX83.2 DB390x.DBX2001.2
Spindle in setpoint range DB31, ... .DBX83.5 DB390x.DBX2001.5
Actual direction of rotation clockwise DB31, ... .DBX83.7 DB390x.DBX2001.7
Rigid tapping active DB31, ... .DBX84.3 DB390x.DBX2002.3
active spindle mode synchronous mode DB31, ... .DBX84.4 DB390x.DBX2002.4
Active spindle positioning mode DB31, ... .DBX84.5 DB390x.DBX2002.5
Active spindle mode oscillation mode DB31, ... .DBX84.6 DB390x.DBX2002.6
Active spindle control mode DB31, ... .DBX84.7 DB390x.DBX2002.7
Spindle actually reached in position DB31, ... .DBX85.5 DB390x.DBX2003.5
M function for spindle DB31, ... .DBB86-87 DB370x.DBD0000
S function for spindle DB31, ... .DBB88-91 DB370x.DBD0004
Sensors available DB31, ... .DBX132.0 DB390x.DBX7000.0
Sensor S1 available (clamped state) DB31, ... .DBX132.1 DB390x.DBX7000.1
Sensor S4 available (piston end position) DB31, ... .DBX132.4 DB390x.DBX7000.4
Sensor S5 available (angular position of the motor shaft) DB31, ... .DBX132.5 DB390x.DBX7000.5
State value is generated, speed limitation p5043 is active DB31, ... .DBX133.2 DB390x.DBX7001.2
Clamped state DB31, ... .DBW134 DB390x.DBW7002
Analog value: Clamped state DB31, ... .DBW136 DB390x.DBW7004
Sensor S4 (piston end position) DB31, ... .DBX138.4 DB390x.DBX7006.4
Sensor S5 (angular position of the motor shaft) DB31, ... .DBX138.5 DB390x.DBX7006.5
Signal name SINUMERIK 840D sl SINUMERIK 828D
