Siemens SINUMERIK 828D Function Manual

A3: Axis Monitoring, Protection Zones
2.5 Examples
Basic Functions
140 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Activation
Table 2-4 Part program excerpt for activating the three protection zones for spindle chuck, workpiece, and toolholder:
NPROT(1, 2, 0, 0, 0) ; Protection zone: Spindle chuck
CPROT(1, 2, 0, 0, 100) ; Protection zone: Workpiece with 100mm offset in the Z
axis.
CPROT(2, 2, 0, 0, 0) ; Protection zone: Toolholder

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
