W1: Tool offset
18.2 Tool
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1427
Effect on the D number
A compensation data set is determined by the D number.
The D address cannot be programmed with an address extension.
The evaluation of the D address always refers to the currently active tool.
The programmed D address refers to the active tool in relation to the master spindle (same as for tool
management function), when machine data is set:
MD20096 $MC_T_M_ADDRESS_EXT_IS_SPINO = TRUE (spindle number as address extension).
Effect on the T number
If the "Tool management" function is active, the values programmed with reference to the master spindle (or
master toolholder) are displayed as programmed/active T numbers.
If tool management is not active, all programmed T values are displayed as programmed/active, regardless of
the programmed address extension.
Only the T value programmed in relation to the master spindle is shown as programmed/active, when:
MD20096 $MC_T_M_ADDRESS_EXT_IS_SPINO = TRUE (spindle number as address extension).
Example
The example below shows the effect of MD20096.
Two spindles are considered. Spindle 1 is the master spindle. M6 was defined as the tool change signal.
T1 = 5
M1 = 6
T2 = 50
M2 = 6
D4
