Siemens SINUMERIK 828D Function Manual

W1: Tool offset
18.4 Tool cutting edge
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1453
3D-face milling
All the tool parameters 6 to 11 are required for tool description of 3D-face milling.
References
Please refer to the following documentation for information about entering tool shapes (radius for tool radius
compensation) in tool parameters 6 to 11 and how these are calculated by geometry tool radius compensation in
the three geometry axes:
• Programming Manual Fundamentals; Chapter: "Tool compensations" > "2½D-tool compensation"
• Functions Manual - Special Functions; 3D-tool radius compensation (W5)
For 3D-face milling, please refer to:
• Programming Manual, Job Planning; Chapter: "Transformations" > "Three, Four and Five axis Transformation
(TRAORI)"
G
K
E
H
D
U
I
KWRROOHQJWK
7RRO3IOHQJWK
7RRO3HOHQJWK
7RRO3GUDGLXV
7RRO3UUDGLXV
7RRO3DDQJOH
7RRO3EDQJOH
