W1: Tool offset
18.10 Special handling of tool compensations
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1555
With the exception of block N40, temperature compensation always acts in the original directions, as the tool is
pointing in the basic orientation direction. This applies particularly in block N50. The tool is actually still pointing in
the direction of the X axis because the B axis is still at 90 degrees. However, because the transformation is
already deactivated, the applied orientation is parallel to the Z axis again.
For more details on "Temperature compensation" see:
References:
/FB2/ Function Manual Extended Functions; Compensations (K3)
For information on "Generic 5-axis transformations" see:
References:
/FB3/ Function Manual Special Functions; 3- to 5Axis Transformation (F2)
MD20390 TOOL_TEMP_COMP_ON = TRUE ; Temperature compensation active
Option ; Activate option
MD32750 TEMP_COMP_TYPE[ AX1 ] = 4 ; Compensation in tool direction
MD32750 TEMP_COMP_TYPE[ AX2 ] = 4 ; Compensation in tool direction
MD32750 TEMP_COMP_TYPE[ AX3 ] = 4 ; Compensation in tool direction
