W1: Tool offset
18.11 Sum offsets and setup offsets
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1559
Supplementary conditions
The maximum number of DL data sets of a cutting edge and the total number of sum offsets in the NCK are
defined by machine data. The default value is zero, i.e., no sum offsets can be programmed.
Activate the "monitoring function" to monitor a tool for wear or for "sum offset".
The additional sum/setup data sets use additional buffered memory. 8 bytes are required per parameter.
A sum-offset data set requires: 8 bytes * 9 parameters = 72 bytes
Tool geometry
parameter, to which the
compensation is added.
Sum/setup parameters, length compensations
Tool wear
parameters
$TC_DP3 Length 1
$TC_SCP13, $TC_SCP23,$TC_SCP33,
$TC_SCP43,$TC_SCP53,$TC_SCP63
$TC_ECP13, $TC_ECP23,$TC_ECP33,
$TC_ECP43,$TC_ECP53,$TC_ECP63
The numbers in bold, 1, 2, ... 6, designate the
parameters of a maximum of six (location-dependent
or similar) compensations that can be programmed
with DL =1 to 6 for the parameter specified in column
one.
$TC_DP12
$TC_DP4 Length 2
$TC_SCP14, $TC_SCP24,$TC_SCP34,
$TC_SCP44,$TC_SCP54,$TC_SCP64
$TC_ECP14, $TC_ECP24,$TC_ECP34,
$TC_ECP44,$TC_ECP54,$TC_ECP64
$TC_DP13
$TC_DP5 Length 3
etc.
$TC_DP14
Radius compensation
$TC_DP6 Radius $TC_DP15
$TC_DP7 Corner radius $TC_DP16
Further compensations
$TC_DP8 Length 4 $TC_DP17
$TC_DP9 Length 5 $TC_DP18
$TC_DP10 Angle 1,
etc.
$TC_DP19
$TC_DP11 Angle 2
$TC_SCP21, $TC_SCP31,$TC_SCP41,
$TC_SCP51,$TC_SCP61,$TC_SCP71
$T
C_ECP21, $TC_ECP31,$TC_ECP41,
$TC_ECP51,$TC_ECP61,$TC_ECP71
The numbers in bold, 2, 3, ... 7, designate the
parameters of a maximum of six (location-dependent
or similar) compensations that can be programmed
with DL =1 to 6 for the parameter specified in column
one.
$TC_DP20
