W1: Tool offset

18.11 Sum offsets and setup offsets

Basic Functions

Function Manual, 09/2011, 6FC5397-0BP40-2BA0

1561

Configuration

MD18112 $MN_MM_KIND_OF_SUMCORR, bit 4=0: (Properties of sum offset in the TO area) default setting:

Only one set of sum offsets exists per DL number.

We refer in general to the sum offset.

This describes the data represented by $TC_SCPx.

Figure 18-50 MD18112 $MN_MM_KIND_OF_SUMCORR, bit 4 = 0

Tool T = t is active. With the data in the figure, the following is programmed:

MD18112 $MN_MM_KIND_OF_SUMCORR, bit 4=1: Setup offsets are available

The sum offset is now composed of the "sum offset fine" (represented by $TC_SCPx) and the setup offset

(represented by $TC_ECPx). Two data sets therefore exist for one DL number. The sum offset is calculated by

adding the corresponding components ($TC_ECPx + $TC_SCPx).

D2 ; Cutting edge offsets, i.e., $TC_DP3 to $TC_DP11 + wear

($TC_DP12 to $TC_DP20) + adapter dimension

...

DL=1 ; Sum offset 1 is added to the previous D2 compensations, i.e.,

$TC_SCP13 to $TC_SCP21.

...

DL=2 ; Sum offset 2 is added to the D2 compensation instead of sum

offset 1, i.e., $TC_SCP23 to $TC_SCP31.

...

DL=0 ; Deselection of sum offset;

only the data of D2 remain active.

'RIIVHW

6XPRIIVHW

6XPRIIVHW

7&B6&3>W@

7&B6&3>W@

7&B6&3>W@

7&B6&3>W@

7&B'3>W@

7&B'3>W@

7&B'3>W@

7&B'3>W@
