W1: Tool offset
18.11 Sum offsets and setup offsets
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1567
Distribution over the geometry-axis components
How the three vector components of partial totals of the vectors involved are distributed over the three geometry-
axis components is determined by the following quantities:
The resulting tool orientation always remains parallel to one of the three axis directions X, Y or Z and exclusively
depends on the active machining plane G17-G19, since it has not yet been possible to assign the tool an
orientation.
Stepless variation of the tool orientation
The toolholder with orientation capability also enables the tool orientation to be varied steplessly, in addition to
providing further offsets or linear expansion fluctuations with the aid of offset vectors l
1
- l
3
.
For more information, see:
References:
/FB1/ Function Manual Basic Functions; Tool Offset (W1),
Section: Toolholder with orientation capability
Minor operator compensations
Minor compensations, however, must also be modified during the normal production mode.
The reasons for this are e.g.:
• Tool wear
• Clamping errors
• Temperature sensitivity of the machine:
These compensations are defined as follows:
Influencing quantity dependencies
Active processing level:
G17 X/Y direction
G18 Z/X direction
G19 Y/Z direction
Infeed plane:
Z
Y
X
Tool type:
Milling tools, drilling tools, grinding tools, turning tools
See:
Section "Tool type", Table "Minimum
number of required tool parameters"
SD42900 $SC_MIRROR_TOOL_LENGTH
SD42910 $SC_MIRROR_TOOL_WEAR
SD42920 $SC_WEAR_SIGN_CUTPOS
SD42930 $SC_WEAR_SIGN
SD42940 $SC_TOOL_LENGTH_CONST
SD42950 $SC_TOOL_LENGTH_TYPE
See:
Sections "Special handling of tool
compensations" and "Setting data".
Adapter transformations See: "FB Tool management"
