Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.1 Various interface signals and functions (A2)
Basic Functions
1640 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Special cases,
errors, ....
Index 0 is returned if the switchover function is disabled with:
MD35590 $MA_PARASET_CHANGE_ENABLE = 0.
In this case, the 1st parameter set is always active.
Corresponding to ... DB31, ...DBX9.0 - DBX9.2 (controller parameter set switchover (request))
DB31, ...
DBX76.0 Lubrication pulse
Edge evaluation: yes Signal(s) updated: cyclic
Edge change
0 → 1
or
1 → 0
As soon as the axis/spindle has moved through the traversing distance set in machine data:
MD33050 $MA_LUBRICATION_DIST (traversing distance for lubrication from the PLC)
, the interface signal is inverted.
Note:
The distance measurement is restarted each time that the control powers up (boots).
Application
example(s)
The lubrication pump for the axis/spindle can be activated with "Lubrication pulse" interface signal.
Machine bed lubrication therefore depends on the distance traveled.
Corresponding to ... MD33050 $MA_LUBRICATION_DIST (lubrication pulse distance)
DB31, ...
DBX92.1 Ramp function generator disable active
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 PLC receives the signal that the ramp function generator fast stop is active.
The function has been activated by the interface signal:
DB31, ... DBX20.1 (ramp-function generator fast stop)
The drive is stopped without a ramp function with speed setpoint = 0 and without pulse suppression.
Signal state 0 Ramp function generator fast stop is not active for the drive.
Application
example(s)
Bypassing the ramp function generator on the servo side
Corresponding to ... DB31, ... DBX20.1 (ramp-function generator fast stop)
Remark In the SINAMICS a protocol can be set that runs in what is known as the 611U compatibility mode.
Additional
references
/IDsl/ Commissioning Manual IBN CNC: NCK, PLC, Drive
DB31, ...
DBX69.0 - DBX69.2
Controller parameter set switchover (A (checkback signal))
Active parameter set
