Z1: NC/PLC interface signals

19.3 Continuouspath mode, exact stop and LookAhead (B1)

Basic Functions

1658 Function Manual, 09/2011, 6FC5397-0BP40-2BA0

Signal irrelevant for

...

Rotary axes that are programmed as rounding axes.

Corresponding to .... MD36010 $MA_STOP_LIMIT_FINE (exact stop fine)

DB31, ...

DBX60.7 Position reached with exact stop fine
