Siemens SINUMERIK 828D

Z1: NC/PLC interface signals
19.4 Travel to fixed stop (F1)
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1661
DB31, ...
DBX62.5 Fixed stop reached
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The fixed stop was reached after selecting the FXS function.
This signal is used by analog drives, e.g. to switch the actuator from speedcontrolled to current or
torquecontrolled mode so that a programmable clamping torque can be set.
Signal state 0 or
edge change
1 → 0
The fixed stop has still not been reached after selecting the FXS function.
