Z1: NC/PLC interface signals
19.6 Mode group, channel, program operation, reset response (K1)
Basic Functions
1672 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
DB11
DBX4.2
Data block
Selected JOG mode
Signal(s) from BAG (HMI → PLC)
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
JOG mode is selected by HMI.
Signal state 0 or
edge change
1 → 0
JOG mode is not selected by HMI.
DB11
DBX5.0 Selected machine function TEACH IN
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
The machine function TEACH IN is selected by HMI within BAG.
Signal state 0 or
edge change
1 → 0
The machine function TEACH IN is not selected by HMI.
Additional
references
/BA/ Operations Guide HMI (corresponding to the used software)
DB11
DBX5.1 Selected REPOS machine function
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
The machine function REPOS is selected by HMI within BAG.
Signal state 0 or
edge change
1 → 0
The machine function REPOS is not selected by HMI.
Application
example(s)
When a fault occurs when executing a part program (e.g. tool breakage), the axis is manually moved
away from the fault location in the JOG mode in order to be able to replace the tool.
The axis can then be manually returned to the exact previous position using the REPOS machine
function so that the program can be continued in the automatic mode.
Additional
references
/BA/ Operations Guide HMI (corresponding to the used software)
DB11
DBX5.2 Selected machine function REF
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
The machine function REF is selected by HMI within BAG.
Signal state 0 or
edge change
1 → 0
The machine function REF is not selected by HMI.
Additional
references
/FB1/ Functions Manual Basic Functions; Reference Point Travel (R1)
