Z1: NC/PLC interface signals
19.6 Mode group, channel, program operation, reset response (K1)
Basic Functions
1674 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
DB11
DBX6.7 All channels in the reset state
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
All the channels that belong to this mode group are in the "channel status reset" state (DB21, ...
DBX7.7).
Signal state 0 or
edge change
1 → 0
At least one of the channels in the mode group is not in "channel status reset" (DB21, ... DBX7.7).
Corresponding to .... DB21, ... DBX7.7 (channel state, reset)
DB11
DBX7.0 Active machine function TEACH IN
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
Machine function TEACH IN is active in the mode group.
Signal state 0 or
edge change
1 → 0
Machine function TEACH IN is not active.
Additional
references
/BA/ Operations Guide HMI (corresponding to the used software)
DB11
DBX7.1 Active REPOS machine function
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
Machine function REPOS is active in the mode group.
Signal state 0 or
edge change
1 → 0
Machine function REPOS is not active.
Application
example(s)
When a fault occurs when executing a part program (e.g. tool breakage), the axis is manually moved
away from the fault location in the JOG mode in order to be able to replace the tool.
The axis can then be manually returned to the exact previous position using the REPOS machine
function so that the program can be continued in the automatic mode.
Further references /BA/ Operations Guide HMI (corresponding to the used software)
DB11
DBX7.2 Active machine function REF
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
Machine function REF is active in the mode group.
Signal state 0 or
edge change
1 → 0
Machine function REF is not active.
Further references /FB1/ Functions Manual Basic Functions; Reference Point Travel (R1)
