Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.6 Mode group, channel, program operation, reset response (K1)
Basic Functions
1678 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Signal state 0 or
edge change
1 → 0
No effect.
Corresponding to ... DB21, ... DBX7.3 (NC stop)
DB21, ... DBX7.4 (NC stop, axes plus spindles)
DB21, ... DBX35.2 (program status stopped)
DB21, ... DBX35.6 (channel status interrupted)
DB21, ...
DBX7.3 NC STOP
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 or
edge change
0 → 1
AUTOMATIC or MDA mode:
Processing of the part program active in the channel is stopped.
The axes (not spindles) are brought to a standstill within the assigned acceleration parameters.
• Program status: stopped
• Channel status: interrupted
JOG mode:
In JOG mode, incompletely traversed incremental paths (INC...) are retracted at the next NC
START.
Note
The signal must be present for at least one PLC cycle (OB1).
Signal state 0 or
edge change
1 → 0
No effect.
Signal irrelevant for
...
• Program status: aborted
• Channel status: Reset
Special cases,
errors, ......
• If data are transferred to the NCK after NC STOP (e.g., tool offset), the data are cleared at the
next NC START.
Corresponding to ... DB21, ... DBX7.2 (NC STOP at block limit)
DB21, ... DBX7.4 (NC STOP axes plus spindles)
DB21, ... DBX35.2 (program status stopped)
DB21, ... DBX35.6 (channel status interrupted)
DB21, ...
DBX7.4 NC STOP axes plus spindles
Edge evaluation: no Signal(s) updated: Cyclic
See DB21, ... DBX7.3 (NC STOP).
In addition, the spindles of the channel are stopped.
DB21, ...
DBX7.7 Reset
Edge evaluation: no Signal(s) updated: Cyclic
Signal state 1 or
edge change
0 → 1
The channel is reset. The initial settings are set (e.g. G functions).
The alarms for the channel are cleared if they are not POWER ON alarms.
The reset signal must be issued by the PLC (e.g., using a logic operation with the reset key on the
MCP). The signal is only evaluated by the selected channel.
The program status changes to "Aborted", and the channel status changes to "Channel status
reset".
DB21, ...
DBX7.2 NC STOP at block limit
