Z1: NC/PLC interface signals
19.6 Mode group, channel, program operation, reset response
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1691
DB21, ...
DBX319.5 Repos DEFERAL Chan
Edge evaluation: No Signal(s) updated: Cyclic
Signal state 1 or
edge change
0 → 1
All axes currently controlled by this channel have either no REPOS offset or their REPOS offsets are
invalid.
Signal state 0 or
edge change
1 → 0
Miscellaneous.
Corresponding to ... DB31, ... DBX70.0 (Repos offset)
DB21, ...
DBB376 ProgEventDisplay
Edge evaluation: No Signal(s) updated: Event-driven
Signal state 1 or
edge change
0 → 1
The event assigned to the bit has activated the "Event-driven program call" function.
Signal state 0 or
edge change
1 → 0
• The event assigned to the bit has not activated the "Event-driven program call" function.
or
• The event-driven user program has expired or was cancelled with RESET.
Bit assignments Bit 0 → part program start from channel status RESET
Bit 1 → end of part program
Bit 2 → operator panel reset
Bit 3 → run-up
Bit 4 → 1st start after the search run
Bit 5 - 7 → reserved, currently always 0
All bits 0 → No event-driven program call is active
Signal duration: at least one complete PLC cycle
DB21, ...
DBX378.0 ASUB is active
Edge evaluation: No Signal(s) updated: Event-driven
Signal state 1 or
edge change
0 → 1
One ASUB is active.
Note:
The user gets a feedback on a running ASUB through DB21, … DBX378.0 even outside FC9 block.
Signal state 0 or
edge change
1 → 0
No ASUB is active.
DB21, ...
DBX378.1 Still ASUB is active
Edge evaluation: No Signal(s) updated: Event-driven
Signal state 1 or
edge change
0 → 1
An ASUB with suppressed display updating (refer to MD20191$MC_IGN_PROG_STATE_ASUP) is
active.
Signal state 0 or
edge change
1 → 0
No ASUB with suppressed display updating is active.
