Siemens SINUMERIK 828D

Z1: NC/PLC interface signals
19.6 Mode group, channel, program operation, reset response (K1)
Basic Functions
1694 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
DB31, ...
DBX76.4 Path axis
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The axis is involved in the path (path axis).
Note
In conjunction with SERUPRO in status "Target block found", the signal refers to the status of the
axis in the target block.
Signal state 0 or
edge change
1 → 0
The axis is not involved in the path.
