Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.10 Reference point approach (R1)
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1701
DB31, ...
DBX60.5 Referenced/synchronized 2
Edge evaluation: Signal(s) updated:
Signal state 1 or
edge change
0 → 1
Axes:
When being referenced, if the machine axis has reached the reference point (incremental measuring
systems) or the target point (for length measuring system with distance-coded reference marks),
then the machine axis is referenced and the following interface signal is set:
DB31, ... DBX60.5 (referenced/synchronized 2)
(depending on which position measuring system is active when referencing).
Spindles:
After power-on, a spindle is synchronized the latest after one spindle revolution (360 degrees) (the
zero mark passed or the Bero responded).
Signal state 0 or
edge change
1 → 0
The machine axis/spindle with position measuring system 2 is not referenced/synchronized.
Axes:
Alarm 21610 was output.
Spindles:
Encoder limit frequency exceeded.
Corresponding to ... DB31, ... DBX1.6 (position measuring system 2)
MD34102 $MA_REFP_SYNC_ENCS (measuring system calibration) = 0
DB31, ...
DBX71.4 POS_RESTORED 1
Edge evaluation: Signal(s) updated:
Signal state 1 or
edge change
0 → 1
If MD34210 $MA_ENC_REFP_STATE is set to a value of 3, the last axis position buffered before
switch off is restored in distance-coded, incremental measuring systems. Referencing does not take
place automatically. Position measuring system 1 is in "Position restored" state.
Signal state 0 or
edge change
1 → 0
The machine axis/spindle with position measuring system 1 is not restored.
Corresponding to ... DB31, ... DBX60.4 (referenced / synchronized 1)
DB31, ...
DBX71.5 POS_RESTORED 2
Edge evaluation: Signal(s) updated:
Signal state 1 or
edge change
0 → 1
If MD34210 $MA_ENC_REFP_STATE is set to a value of 3, the last axis position buffered before
switch off is restored in distance-coded, incremental measuring systems. Referencing does not take
place automatically. Position measuring system 2 is in "Position restored" state.
Signal state 0 or
edge change
1 → 0
The machine axis/spindle with position measuring system 2 is not restored.
Corresponding to ... DB31, ... DBX60.5 (referenced / synchronized 2)
