Siemens SINUMERIK 828D Function Manual

Z1: NC/PLC interface signals
19.12 Feeds (V1)
Basic Functions
Function Manual, 09/2011, 6FC5397-0BP40-2BA0
1719
DB21, ...
DBB4 Feedrate override
Edge evaluation: No Signal(s) updated: Cyclically
Signal state 1 or
edge change
0 → 1
The feedrate override can be defined via the PLC in binary or Gray coding.
With binary coding, the feed value is interpreted in %.
0% to 200% feed changes are possible, in accordance with the binary value in the byte.
The following permanent assignment applies:
Binary values > 200 are limited to 200%.
The machine data:
MD12100 $MN_OVR_FACTOR_LIMIT_BIN (limit for binary-coded override switch)
can be used to additionally limit the maximum feedrate override.
With Gray coding, the individual switch settings are assigned to the following code.
&RGH
)HHGUDWHRYHUULGHIDFWRU






ฬ
ฬ
ฬ
ฬ

ฬ

Siemens SINUMERIK 828D Specifications

General

Control Type	CNC
Operating System	Windows Embedded
Processor	Intel Atom
Display	10.4" color TFT display
Interfaces	Ethernet, USB
Programming	ShopMill, ShopTurn
Operation Panel Size	10.4"
Protection Class	IP65
PLC Memory	2 MB
Spindle Capacity	4 spindles
Hard Drive	CompactFlash
