Z1: NC/PLC interface signals
19.12 Feeds (V1)
Basic Functions
1722 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Signal state 1 or
edge change
0 → 1
The factors listed in the table for the rapid traverse override are stored in the machine data:
MD12050 $MN_OVR_FACTOR_RAPID_TRA[n].
The table contains the default settings.
The number of possible switch settings for standard machine panels is described in the
Configuration Guides for SINUMERIK840D.
Corresponding to .... DB21, ... DBX6.6 (rapid traverse override active)
MD12050 $MN_OVR_FACTOR_RAPID_TRA[n] (evaluation of the path feed rate override switch)
MD12100 $MN_OVR_FACTOR_LIMIT_BIN (limit for binary coded override switch)
DB21, ...
DBB5 Rapid traverse override
7DEOH*UD\FRGLQJIRUUDSLGWUDYHUVHRYHUULGH
6ZLWFK
SRVLWLRQ
&RGH 5DSLGWUDYHUVH
RYHUULGHIDFWRU
VWDQGDUGYDOXHV
