Z1: NC/PLC interface signals
19.12 Feeds (V1)
Basic Functions
1732 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Signal state 1 or
edge change
0 → 1
In gray coding, the following codes are assigned to the individual switch settings:
The factors listed in the table for spindle override are stored in the machine data:
MD12070 $MN_OVR_FACTOR_SPIND_SPEED [n]
The table contains the default settings.
The number of possible switch settings for standard machine panels is described in the
Configuration Guides for SINUMERIK840D.
Corresponding to .... DB31, ... DBX1.7 (override active)
MD12070 $MN_OVR_FACTOR_SPIND_SPEED [n] (evaluation of the spindle override switch)
MD12100 $MN_FACTOR_LIMIT_BIN (limit for binary-coded override switch)
DB31, ...
DBB19 Spindle override
7DEOH*UD\FRGLQJIRUVSLQGOHRYHUULGH
6ZLWFK
SRVLWLRQ
&RGH
6SLQGOHRYHUULGH
IDFWRU
VWDQGDUGYDOXHV
