D1: Diagnostics tools
5.3 Service overview
Basic Functions
290 Function Manual, 09/2011, 6FC5397-0BP40-2BA0
Table 5-4 Diagnostic screen Axis Info
Function/Part function Explanation/Meaning
Machine axis Name of the axis defined in the NC-machine data
Output
Slave/Slot Configured routing
State Current state of slot.
Green lamp: Cyclic communication
Red lamp: (still) no cyclic communication
Telegram failures It is shown, how many telegram failures have occured since the NC-power up. This
value is an indication of the quality (susceptibility to faults) of the PROFIBUS-DP
strand.
Encoder 1
Slave/Slot Configurable routing
State Current state of slot.
Green lamp: Cyclic communication
Red lamp: (still) no cyclic communication
Telegram failures It is shown, how many telegram failures have occured since the NC-power up. This
value is an indication of the quality (susceptibility to faults) of the PROFIBUS-DP
strand.
Type Display of the encoder type configured in the NC-machine data.
ABS: Absolute encoder
INC: Incremental value encoder
Encoder 2 (If configured, the same display as for encoder 1)
